| Model |
SUN-60K-SG02HP3
-AU-EM6 |
SUN-70K-SG02HP3
-AU-EM6 |
SUN-75K-SG02HP3
-AU-EM6 |
SUN-80K-SG02HP3
-AU-EM6 |
| Battery Input Data |
|
| Battery Type |
Lithium-ion |
| Battery Voltage Range(V) |
160-1000 |
| Max.Charging Current(A) |
80+80 |
| Max.Discharging Current(A) |
80+80 |
| Charging Strategy for Li-ion Battery |
Self-adaption to BMS |
| Number of Battery Input |
2 |
| PV String Input Data |
|
|
|
|
Max. PV access power(W)
|
120000 |
140000 |
150000 |
160000 |
| Max PV Input Power（W） |
96000 |
112000 |
120000 |
128000 |
| Max. PV Input Voltage (V) |
1000 |
| Start-up Voltage（V） |
180 |
| MPPT Voltage Range (V) |
150-850 |
| Rated PV Input Voltage (V) |
650 |
| Max. Operating PV Input Current (A) |
36+36+36+36+36+36 |
| Max. Input Short-Circuit Current (A) |
54+54+54+54+54+54 |
No. of MPP Trackers/
No. of Strings MPP Tracker |
6/2+2+2+2+2+2 |
| AC Input/Output Data |
|
|
|
| Rated AC Input/Output Active Power (W) |
60000 |
70000 |
75000 |
80000 |
| Max. AC Input/Output Apparent Power (VA) |
60000 |
70000 |
75000 |
80000 |
| Rated AC Input/Output Current (A) |
87 |
101.5 |
108.7 |
116 |
| Max. AC Input/Output Current (A) |
87 |
101.5 |
108.7 |
116 |
| Max. Continuous AC Passthrough (grid to load) (A) |
200 |
| Peak Power (off grid) |
1.5 times of rated power, 10s |
| Power Factor Adjustment Range |
0.8 leading to 0.8 lagging |
| Rated Input/Output Voltage/Range (V) |
230/400V 240/415V 0.85Un-1.1Un |
| Rated Input/Output Grid Frequency/Range(Hz) |
50Hz/45Hz-55Hz |
| Grid Connection Form |
3L+N+PE |
| Total Current Harmonic Distortion THDi |
<3% |
| DC Injection Current |
<0.5%ln |
| Efficiency |
|
| Max Efficiency |
98.70% |
| Euro Efficiency |
98.10% |
| MPPT Efficiency |
>99% |
| Equipment Protection |
|
| Integrated |
DC Reverse Polarity Protection, AC Output Overcurrent Protection, Thermal Protection,AC Output Overvoltage Protection, AC Output Short Circuit Protection, DC Component Monitoring,Insulation Impedance Detection, Arc Fault Circuit Interrupter (optional),DC Switch,Anti-islanding Protection(Active Frequency shift) , Residual Current Detection |
| Surge Protection Leve |
TYPE II(DC), TYPE II(AC) |
| Interface |
|
| Communication Interface |
RS485/RS232/CAN |
| LCD/LED Display |
LCD+LED |
| General Data |
|
| Operating Temperature Range (℃) |
-40 to +60℃, >45℃ Derating |
| Permissible Ambient Humidity |
0-100% |
| Permissible Altitude |
3000m |
| Noise (dB) |
≤65 |
| Ingress Protection(IP) Rating |
IP 65 |
|
Protection Level
|
Class I
|
| Inverter Topology |
Non-Isolated |
| Over Voltage Category |
OVC II(DC), OVC III(AC) |
| Cabinet Size (WxHxD mm) |
606×927×314
(Excluding Connectors and Brackets) |
| Weight (kg） |
105 |
| Type of Cooling |
Smart Cooling |
| Warranty |
10 Years |
| Grid Regulation |
AS/NZS 4777.2 |
| Safety / EMC Standard |
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 |
