| Model |
SUN-100K-SG02HP3-AU-GM8 |
SUN-100K-SG02HP3-AU-GM10 |
SUN-125K-SG02HP3-AU-GM10 |
| Battery Input Data |
| Battery Type |
Lithium-ion |
| Battery Voltage Range(V) |
160-1000 |
| Max. Charging/Discharging Current (A) |
100+100 |
| Charging Strategy for Li-ion Battery |
Self-adaption to BMS |
| Number of Battery Input |
2 |
| PV String Input Data |
| Max. PV Access Power (W) |
200000 |
200000 |
250000 |
| Max. PV Input Power（W） |
160000 |
160000 |
200000 |
| Max. PV Input Voltage（V） |
1000 |
| Start-up Voltage（V） |
180 |
| MPPT Voltage Range（V） |
150-850 |
| Rated PV Input Voltage(V) |
650 |
| Max. Operating PV Input Current (A) |
42+42+42+42+42+42+42+42 |
42+42+42+42+42+42+42+42+42+42 |
| Max. Input Short-Circuit Current (A) |
63+63+63+63+63+63+63+63 |
63+63+63+63+63+63+63+63+63+63 |
| No.of MPP Trackers/No.of String MPP Tracker |
8/2+2+2+2+2+2+2+2 |
10/2+2+2+2+2+2+2+2+2+2 |
| AC Input/Output Data |
| Rated AC Input/Output Active Power（W） |
100000 |
100000 |
125000 |
| Rated/Max AC Input/Output Apparent Power （VA） |
100000 |
100000 |
125000 |
| Rated AC Input/Output Current（A） |
145.0 |
145.0 |
181.2 |
| Max. AC Input/Output Current（A） |
145.0 |
145.0 |
181.2 |
| Max. Continuous AC Passthrough (grid to load)（A） |
250 |
| Peak Power (off-grid) (W) |
1.5 times of rated power, 10s |
| Power Factor Adjustment Range |
0.8 leading to 0.8 lagging |
| Rated input/output voltage |
230/400V, 240/415V 0.85Un-1.1Un 3L+N+PE
|
| Rated Input/Output Grid Frequency/Range(Hz) |
50/45-55 |
| Total Current Harmonic Distortion THDi |
<3% (of nominal power) |
| DC Injection Current |
<0.5%ln |
| Generator Data |
| Nominal Input Voltage (V) |
230/400V, 240/415V |
| Rated Input Current (A) |
200 |
| Power Factor |
0.8 leading-0.8 lagging |
| Frequency |
50Hz |
| Backup Data |
| Nominal Input Voltage (V) |
230/400V, 240/415V |
| Rated Output Current (A) |
145.0 |
145.0 |
181.2 |
| Rated Apparent Power (VA) |
100000 |
100000 |
125000 |
| Power Factor |
0.8 leading-0.8 lagging |
| Frequency |
50Hz |
| Efficiency |
| Max. Efficiency |
98.70% |
| Euro Efficiency |
98.10% |
| MPPT Efficiency |
＞99% |
| Equipment Protection |
| Integrated |
DC Reverse Polarity Protection, AC Output Overcurrent Protection, Thermal Protection,
AC Output Overvoltage Protection, AC Output Short Circuit Protection, DC Component Monitoring,
Arc Fault Circuit Interrupter (AFCI) (optional), Anti-islanding Protection (Active Frequency shift),
DC Switch, Insulation Impedance Detection, Residual Current Detection |
| Surge Protection Level |
TYPE II(DC), TYPE II(AC) |
| Interface |
| LCD/LED Display |
LCD+LED |
| Communication Interface |
RS485,RS232,CAN |
| General Data |
| Operating Temperature Range(℃) |
-40 to +60℃, >45℃ Derating |
| Permissible Ambient Humidity |
0-100% |
| Permissible Altitude |
3000m |
| Noise (dB) |
≤ 65 |
| Ingress Protection(IP) Rating |
IP 65 |
| Protection Level |
Class I |
| Inverter Topology |
Non-Isolated |
| Over Voltage Category |
OVC II(DC),OVC III(AC) |
|
Cabinet Size (WxHxD mm)
|
734×1091×344 (Excluding Connectors and Brackets)
|
|
Weight (kg)
|
161.7
|
| Type of Cooling |
Intelligent Air Cooling |
| Warranty |
10 Years
|
| Grid Regulation |
AS/NZS 4777.2 |
| Safety / EMC Standard |
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 |
