| Model |
SUN-29.9K-SG02HP3-AU-BM3-P |
SUN-30K-SG02HP3-AU-BM3-P |
SUN-35K-SG02HP3-AU-BM3-P |
SUN-40K-SG02HP3-AU-BM4-P |
SUN-50K-SG02HP3-AU-BM4-P |
| Battery Input Data |
|
| Battery Type |
Lithium-ion |
| Battery Voltage Range(V) |
160-800 |
| Max. Charging/Discharging Current (A) |
160 |
| Charging Strategy for Li-ion Battery |
Self-adaption to BMS |
| Number of battery input |
1 |
| PV String Input Data |
|
|
Max. PV Access Power (W)
|
59800 |
60000 |
70000 |
80000 |
100000 |
| Max. PV Input Power（W） |
47840 |
48000 |
56000 |
64000 |
80000 |
| Max. PV Input Voltage（V） |
1000 |
| Start-up Voltage（V） |
180 |
| MPPT Voltage Range（V） |
150-850 |
| Rated PV Input Voltage(V) |
600 |
| Max. Operating PV Input Current（A） |
36+36+36 |
36+36+36+36 |
| Max. Input Short-Circuit Current（A） |
55+55+55 |
55+55+55+55 |
| No.of MPP Trackers/No.of Strings MPP Tracker |
3/2+2+2 |
4/2+2+2+2 |
| AC Input/Output Data |
|
| Rated AC Input/Output Active Power（W） |
29900 |
30000 |
35000 |
40000 |
50000 |
| Max. AC Input/Output Apparent Power （VA） |
29900 |
30000 |
35000 |
40000 |
50000 |
| Rated AC Input/Output Current（A） |
43.4 |
43.5 |
50.8 |
58 |
72.5 |
| Max. AC Input/Output Current（A） |
43.4 |
43.5 |
50.8 |
58 |
72.5 |
| Max. Continuous AC Passthrough (grid to load)（A） |
200 |
| Peak Power (off-grid)（W） |
1.5 times of rated power,10s |
| Power Factor Adjustment Range |
0.8 leading to 0.8 lagging |
| Rated input/output voltage |
230/400V 240/415V 0.85Un-1 .1Un 3L+N+PE |
| Rated Input/Output Grid Frequency/Range(Hz) |
50/45-55 |
| Total Current Harmonic Distortion THDi |
<3% (of nominal power) |
| DC Injection Current |
<0.5%ln |
| Generator Data |
|
| Nominal Input Voltage (V) |
230/400V 240/415V |
| Rated Input Current (A) |
200 |
| Power Factor |
0.8 leading-0.8 lagging |
| Frequency |
50Hz |
| Backup Data |
|
| Nominal Output Voltage (V) |
230/400V 240/415V |
| Rated Output Current（A） |
43.3 |
43.5 |
50.8 |
58 |
72.5 |
| Rated Apparent Power (VA) |
29900 |
30000 |
35000 |
40000 |
50000 |
| Power Factor |
0.8 leading-0.8 lagging |
| Frequency |
50Hz |
| Efficiency |
|
| Max. Efficiency |
97.6% |
| Euro Efficiency |
97.0% |
| MPPT Efficiency |
＞99% |
| Equipment Protection |
|
|
Integrated
|
DC Reverse Polarity Protection, AC Output Overcurrent Protection, Thermal Protection,
AC Output Overvoltage Protection, AC Output Short Circuit Protection, DC Component Monitoring,
Arc Fault Circuit Interrupter (AFCI) (optional), Anti-islanding Protection(Active Frequency shift),
DC Switch, Insulation Impedance Detection, Residual Current Detection
|
| Surge Protection Level |
TYPE II(DC), TYPE II(AC) |
| Interface |
|
| LCD/LED Display |
LCD+LED |
|
|
|
| General Data |
|
| Operating Temperature Range (℃) |
-40 to +60℃, >45℃Derating |
| Permissible Ambient Humidity |
0-100% |
| Permissible Altitude |
3000m |
| Noise (dB) |
≤ 65 |
| Ingress Protection(IP) Rating |
IP 65 |
| Protection Level |
Class I |
| Inverter Topology |
Non-Isolated |
| Over Voltage Category |
OVC II(DC),OVC III(AC) |
| Cabinet Size (WxHxD mm) |
528×793×278 (Excluding Connectors and Brackets) |
| Weight (kg) |
65 |
| Type Of Cooling |
Intelligent Air Cooling |
| Warranty |
10 Years |
| Grid Regulation |
AS/NZS 4777.2 |
| Safety / EMC Standard |
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 |
