| Model |
SUN-7K-SG06LP1-AU-BM3 |
SUN-7.6K-SG06LP1-AU-BM3 |
SUN-8K-SG06LP1-AU-BM3 |
SUN-10K-SG06LP1-AU-BM3 |
SUN-12K-SG06LP1-AU-BM3 |
| Battery Input Data |
|
| Battery Type |
Lead-acid or Lithium-ion |
| Battery Voltage Range(V) |
40-60 |
| Max. Charging/Discharging Current (A) |
175 |
185 |
185 |
220 |
250 |
| Charging Strategy for Li-ion Battery |
Self-adaption to BMS |
| Number of Battery Input |
1 |
| PV String Input Data |
|
|
Max. PV Access Power (W)
|
14000 |
15200 |
16000 |
20000 |
24000 |
| Max. PV Input Power（W） |
11200 |
12160 |
12800 |
16000 |
19200 |
| Max. PV Input Voltage（V） |
500 |
| Start-up Voltage（V） |
125 |
| MPPT Voltage Range（V） |
150-425 |
| Rated PV Input Voltage(V) |
370 |
| Max. Operating PV Input Current (A) |
36+18+18
|
36+36+18 |
| Max. Input Short-Circuit Current (A) |
54+27+27
|
54+54+27 |
| No.of MPP Trackers/No.of Strings MPP Tracker |
3/2+1+1
|
3/2+2+1 |
| AC Input/Output Data |
|
| Rated AC Input/Output Active Power（W） |
7000 |
7600 |
8000 |
9999
|
12000 |
| Max. AC Input/Output Apparent Power（VA） |
7000 |
7600 |
8000 |
9999
|
12000 |
| Rated AC Input/Output Current（A） |
30.5 |
33.1 |
34.8 |
43.5 |
52.2 |
| Max. AC Input/Output Current（A） |
30.5 |
33.1 |
34.8 |
43.5 |
52.2 |
| Max. Continuous AC Passthrough (grid to load)（A） |
63 |
| Peak Power (off-grid)（W） |
2 times of rated power,10s
|
| Power Factor Adjustment Range |
0.8 leading to 0.8 lagging |
| Rated Input/Output Voltage/Range (V) |
230/240V 0.85Un-1.1Un L+N+PE |
| Rated Input/Output Grid Frequency/Range(Hz) |
50/45-55 |
| Total Current Harmonic Distortion THDi |
<3% (of nominal power) |
| DC Injection Current |
<0.5%ln |
| Generator Data |
|
| Nominal Input Voltage (V) |
230/400V |
| Rated Input Current (A) |
65 |
65 |
65 |
65 |
70 |
| Power Factor |
0.8 leading-0.8 lagging |
| Frequency |
50Hz |
| Backup Data |
|
| Nominal Output Voltage (V) |
230/400V |
| Rated Output Current (A) |
30.5 |
33.1 |
34.8 |
43.5 |
52.2 |
| Rated Apparent Power (VA) |
7000 |
7600 |
8000 |
9999 |
12000 |
| Power Factor |
0.8 leading-0.8 lagging |
| Frequency |
50Hz |
| Efficiency |
|
| Max. Efficiency |
97.6% |
| Euro Efficiency |
96.5% |
| MPPT Efficiency |
＞99% |
| Equipment Protection |
|
|
Integrated
|
DC Reverse Polarity Protection, AC Output Overcurrent Protection, Thermal Protection,
AC Output Overvoltage Protection, AC Output Short Circuit Protection, DC Component Monitoring,
Arc Fault Circuit Interrupter (AFCI) (optional), Anti-islanding Protection (Active Frequency shift),
DC Switch, Insulation Impedance Detection, Residual Current Detection
|
| Surge Protection Level |
TYPE II(DC),TYPE II(AC) |
| Interface |
|
| LCD/LED Display |
LCD |
| Communication Interface |
WIFI, RS485, CAN |
| General Data |
|
| Operating Temperature Range (℃) |
-40 to +60℃, >45℃ Derating
|
| Permissible Ambient Humidity |
0~100% |
| Permissible Altitude |
3000m |
| Noise (dB) |
＜45 |
| Ingress Protection(IP) Rating |
IP 65 |
| Protection Level |
Class I |
| Inverter Topology |
Non-Isolated (solar), Isolated (battery) |
| Over Voltage Category |
OVC II(DC), OVC III(AC) |
| Cabinet Size (WxHxD mm) |
340×580×227 (Excluding Connectors and Brackets) |
| Weight (kg) |
23.7
|
24.5 |
| Type Of Cooling |
Intelligent Air Cooling |
| Warranty |
10 Years |
| Grid Regulation |
AS/NZS 4777.2 |
|
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 |
