| Model |
SUN-120K-G01P3 |
SUN-125K-G01P3 |
SUN-130K-G01P3 |
SUN-135K-G01P3 |
SUN-136K-G01P3 |
|
|
|
|
|
| PV String Input Date |
|
|
|
|
|
|
| Max. PV Input Power(kW) |
180 |
187.5 |
195 |
202.5 |
204 |
|
|
|
|
|
| Max. PV Input Voltage(V) |
1100 |
|
|
|
|
|
| Start-up Voltage(V) |
250 |
|
|
|
|
|
| MPPT voltage range(V) |
200-1000 |
|
|
|
|
|
| Rated PV Input voltage(V) |
600 |
|
|
|
|
|
| Max. Input Short Circuit Current (A) |
60+60+60+60+60+60+60+60 |
|
|
|
|
|
| Max. Operating PV Input Current(A) |
40+40+40+40+40+40+40+40 |
|
|
|
|
|
| No. of MPP Trackers/No. of Strings per MPP Tracker |
8/4+4+4+4+4+4+4+4 |
|
|
|
|
|
|
AC Output Side
|
|
|
|
|
|
|
| Rated AC Output Active Power(kW) |
120 |
125 |
130 |
135 |
136 |
|
|
|
|
|
| Max. AC Output Apparent Power(kVA) |
132 |
135 |
135 |
135 |
136 |
|
|
|
|
|
| Rated AC output current (A) |
181.9/174 |
189.4/181.2 |
197/188.5 |
204.6/195.7 |
206.1/197.2 |
|
|
|
|
|
| Max. AC Output Current(A) |
200/191.4 |
204.6/195.7 |
204.6/195.7 |
204.6/195.7 |
206.1/197.2 |
|
|
|
|
|
| Rated output voltage/range (V) |
220/380V, 230/400V 0.85Un-1.1Un
|
|
|
|
|
|
| Grid Connection Form |
3L+N+PE |
|
|
|
|
|
| Rated Output Grid Frequency/range(Hz) |
50/45-55, 60/55-65
|
|
|
|
|
|
| Power Factor Adjustment Range |
0.8 leading to 0.8lagging |
|
|
|
|
|
| Total Current Harmonic Distortion THDi |
<3% |
|
|
|
|
|
| DC Injection Current |
<0.5%ln |
|
|
|
|
|
| Efficiency |
|
|
|
|
|
|
| Max. Efficiency |
98.8% |
|
|
|
|
|
| Euro Efficiency |
98.2% |
|
|
|
|
|
| MPPT Efficiency |
＞99% |
|
|
|
|
|
| Equipment Protection |
|
|
|
|
|
|
| DC Reverse Polarity Protection |
Yes |
| AC Output Overcurrent Protection |
Yes |
| AC Output Overvoltage Protection |
Yes |
| AC Output Short Circuit Protection |
Yes |
| Thermal Protection |
Yes |
| Insulation Impedance Detection |
Yes |
| DC Component Monitoring |
Yes |
|
Arc Fault Circuit Interrupter (AFCI)
|
Optional
|
|
Anti-islanding Protection
|
Yes |
| Residual Current Detection |
Yes |
| Surge Protection Level |
TYPE II(DC),TYPE II(AC) |
|
DC Switch
|
Yes |
| Interface |
|
|
|
|
|
|
| Communication Interface |
RS485/RS232 |
|
|
|
|
|
|
Monitor Mode
|
GPRS/WIFI/Bluetooth/4G/LAN(optional) |
|
|
|
|
|
| General Data |
|
|
|
|
|
|
| Operating Temperature Range (°C) |
‘-25 to +60℃, >45℃ Derating |
|
|
|
|
|
| Permissible Ambient Humidity |
0~100% |
|
|
|
|
|
| Permissible Altitude (m) |
4000m |
|
|
|
|
|
| Noise (dB) |
≤ 65 |
|
|
|
|
|
| Ingress Protection(IP) Rating |
IP 65 |
|
|
|
|
|
| Inverter Topology |
Non-Isolated |
|
|
|
|
|
| Over Voltage Category |
OVC II(DC),OVC III(AC) |
|
|
|
|
|
| Cabinet Size (WxHxD mm) |
1006mm*516mm*325.5mm（Excluding connectors and brackets） |
|
|
|
|
|
| Weight [kg] |
103 |
|
|
|
|
|
| Warranty |
5 years |
|
|
|
|
|
| Type Of Cooling |
Intelligent air cooling |
|
|
|
|
|
| Grid Regulation |
IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002,
OVE-Richtlinie R25, G99, VDE-AR-N 4105
|
|
|
|
|
|
| Safety EMC/Standard |
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 |
|
|
|
|
|
